JS500 Concrete Mixer

Share to:

  • JS500
  • ZCJK
  • Model: JS500
  • Trademark: ZCJK
  • Origin: Beijing
  • Packing: standard seaworthy package
  • Unit: set
  • Min order: one
  • TransTime: 15-20 days after order
  • Transportation: Ocean Transport
  • Payment: T/T
Quantity:

JS500 Concrete Mixer

Functions: It is a kind of twin-shaft compulsory mixer. It is applicable for the industrial and commercial projects such as road building, bridge building, hydraulic projects, and port constructions and so on. It can mix both dry and wet concrete.





Name of commodity

JS500

Charging capacity(L)

800

Discharging capacity(L)

500

Productivity (m3/h)

≥25

Max. Diameter of the aggregate(mm)

80/60

Speed of the mixer vane(r/min)

35

Total power(kw)

24.75

Speed of the lifting hopper (m/min)

18

Discharge form

Manual/Pneumatic

Mixing blade quantity

2*7

dimensions(mm) transport status

3000×2300×2680

Gross weight(kg)

4300





 Technical specifications


        Model         JS500
        Discharging capacity         500 L
        Feeding capacity         800 L
        Max production rate         ≥25m³/h
        Maximum aggregate sizes (pebbles)         80mm
        Maximum aggregate sizes(gravel)         60mm
        Mixing blade (rational speed )         35r/min
        Mixing blade (quantity)         2*7
        Mixing motor(power)         18.5kw
        Hoist motor(power)         5.5kw
        Pump motor (power)         0.75kw
        Discharge form         Manual/ Pneumatic
        Size (Transporting status )         3000*2300*2680mm
        Size (Working status)         4450*3000*5390mm
        Weight (KG)         4300
        Discharge height (m )         1.5/ 2.7/3.8
