JCD350 climbing bucket mixer

Share to:

  • ZCJK350+Concrete mixer
  • ZCJK+concrete mixer
  • Model: JDC350
  • Trademark: ZCJK
  • Origin: Beijing
  • Packing: standard seaworthy package
  • Unit: set
  • Min order: one
  • TransTime: 15-20 days after order
  • Transportation: Ocean Transport
  • Payment: T/T
Quantity:
JDC350 Climbing bucket mixer
JDC350 Mixer (1)



Technical specifications
model JDC 350
nominal capacity 350L
rated feeding capacity 560L
maximum aggregate particles 80mm
mixing time 5 times
theoritic production capacity 17.5cubic/h
stirring speed 25r/min
speed of nopper enhance 19m/mmin
mixing moter 15kw
brake moter 4.5kw
pump 0.75kw
method water supply automatic water supply
weight 3000kg
size 3100x2640x4300mm
Mixing time(s) 30s



 Technical Parameter


Model JDC350
Nominal capacity 350L
Rated feeding capacity 560L
Mamimum aggregate particles 80mm
Mixing time 30s
Working cycle times 5s
Theoritic production capacity 17.5m³/h
Stirring Speed 27.6min
Speed of hopper enhance 19m/min
Mixing motor 15kw
Brake motor 4.5kw
Pump 0.75kw
Method of water supply Time  relay
Weight 3000 kg
Size 3100*2640*4300mm
